Celestion T5916: 1" 12W HF Driver 8 Ohm

Celestion T5916: 1" 12W HF Driver 8 Ohm

$60.76
$60.76
Sale Sold out
Taxes included. Shipping calculated at checkout.
$51.64Member price · save 15%

Not a member? Become a member for only $15 per month.

Become a member

Member benefits

  • 15% off every order, storewide
  • Free express shipping, always
  • Entry to the weekly $1,000 giveaway

Very lightweight, low-profile ferrite magnet compression driver.

12Wrms (AES standard) power handling and 106dB sensitivity, 1500-20,000Hz frequency range.

Finite Element Analysis (FEA) techniques used to optimise both magnetic and acoustic design.

Ideal for entry-level two-way and three-way sound reinforcement cabinets.

Key Features:

  • Power rating 12Wrms
  • Nominal impedance 8O
  • Frequency range 1500-20,000Hz
  • Sensitivity 106dB
  • Recommended min. crossover (12dB/oct) 2200Hz
  • Voice coil diameter 25mm/1.0in
  • Voice coil material Copper clad aluminium
  • Magnet type Ferrite
  • Diaphragm material PETP film
  • Surround material PETP film

What's in the box:

  • 1 x Celestion 1" 12W HF Driver 8 Ohm

Key Features

  • Extremely light and compact ferrite magnet compression driver
  • Handles 12W power with 106dB sensitivity, covering 1500-20,000Hz range
  • Utilizes FEA methods for top magnetic and acoustic optimization

Specifications

Brand CELESTION
Model 28/CDX1-1070
Barcode (EAN) 739894591645
Speaker Type PA Speakers
Product Depth (mm) 90.0
Product Width (mm) 90.0
Product Height (mm) 60.0
Product Weight (kg) 0.5
Accessory type Speakers
Manufacturer's warranty 12 Months
